PORTFOLIO
Samples shown are representative of our drafting work.
SAMPLE WORK
Boundary Survey Plat
Full boundary retracement with monumentation and legal description.
SAMPLE WORK
Commercial Site Plan
Site Layout and civil design for commerical development .
SAMPLE WORK
Drainage and Grading Study
Model stormwater flow to eliminate ponding and meet drainage requirements.
SAMPLE WORK
Subdivision Plat
Multi-lot layout with roadway, easements, and configuration ready for recording.
SAMPLE WORK
Topographic Survey
Combined multiple parcels into one legally described lot, reconciling separate deeds into a single clean boundary.
SAMPLE WORK
Joint Boundary Plat
Combined multiple parcels into one legally described lot, reconciling separate deeds into a single clean boundary.
